Technical Parameter
Signal Output | Lock signal NO/COM (YM-500NW-S) |
Size | 230Lx72Wx37.8H(mm) |
Armature plate | 185Lx60Wx13.2H(mm) |
Holding Force | 500kg(1200Lbs) |
Voltage | DC12V (Adjustable DC24V) |
Current | 12V/500mA(±10%) ;24V/250mA(±10%) |
Suitable for | Wooden door , Glass door ,Metal door , Fireproof door |
Surface Temp | ≤+20℃ |
Operating Temp | -20℃~+55℃(-4—131°F) |
Humidity | 0~95%(non-condensing) |
Material of housing | 304 Stainless steel |
Finishes for Magnetic | Zinc |
Finishes for Armature | Zinc |
IP rate | IP-68 |
Weight | 4.5kg |
Certificate | MA CE-EMC CE-LVD FCC RoHS REACH IP68 |
