Technical Parameter
Size | 520Lx54.7Wx29.6H(mm) |
Armature Plate Dimension | 190Lx45Wx13.2H(mm) |
Holding Force | 350kg(800Lbs) *2 |
Input Voltage | DC12V (Adjustable DC24V) |
Current | 12V/500mA(±10%)*2 ; 24V/250mA(±10%)*2 |
LED | Red shows locked ;Green shows unlocked |
Signal Output | Lock signal(NO/NC/COM) |
Time | 0/3/6/9sec. |
Suitable | Wooden door , Glass door ,Metal door , Fireproof door |
Surface Temp | ≤+20℃ |
Operating Temp | -20℃~+55℃(-4—131°F) |
Humidity | 0~95%(non-condensing) |
Weight | 5.4KG |
Certificate | MA CE-EMC CE-LVD FCC RoHS |
