Mini single door concealed magnetic lock

YM-60M is a mini single electric lock, it is designed for showcase, cabinet door and easy to install .Accessories are available for inward door, frameless glass door and narrow doorframe door. Special anti-residual magnetism designed.

SKU: YM-60M Categories: ,

Technical Parameter

Size 130Lx30Wx25H(mm)
Armature Plate Dimension 80Lx32Wx10H(mm)
Holding Force 60kg(120Lbs)
Input Voltage DC12V (Adjustable DC24V)
Current 140mA(±10%)
Suitable File Cabinet ,Display Cabinet
Surface Temp ≤+20℃
Operating Temp -20℃~+55℃(-4—131°F)
Humidity 0~95%(non-condensing)
Weight 0.6KG
Certificate CE-EMC CE-LVD FCC REACH WEEE

Advantage

Collinear Load Test 60kg,120pounds.

MOV Provides Reverse Current Protection.

Anti-Residual Magneism Designed.

High Strength Material,Anodized Aluminum Housing.

Design with no Mechanical Bolt.

Increase the holding Force,Dual Insulative Hosing.

CE Certificate by European Union,MA Certificate by China Public Security Office.

Dimension Diagram

Installation Diagram
