Technical Parameter
Feature | Fail Safe |
Face Plate | 255Lx34WX38H(mm) |
Strike | 100Lx25Wx3W(mm) |
Bolt | 16(length)*16(diameter)(mm) |
Voltage | 12-24VDC |
Start Current | 1200mA |
Standby Current | 280mA |
Solid Bolt | polishing housing, 2000Kg Holding Force |
Suitable For | Heavy door,Wooden door,meta doorl,fireproof door,glass door |
LED | Light on indicates locked, light off indicates unlocked |
Autolock Time Delay | 0,3,6,9sec |
Signal Output | Lock signal:NO/NC/COM Door signal:NO/COM |
Surface Temp | Low Temperature |
Detection Distance | Within 8mm |
Special Designed | Tested to 500000 cycles |
Material | 304 stainless steel, wire draw finishing |
