Technical Parameter
Magnet | 265L×30W×30D (mm) |
Armature | 265L×30W×36.4D (mm) |
Voltage | 12VDC/24VDC(Adjustable) |
Operation Current | 1800mA |
Standby | 500mA |
Time Delay | 0/5/10/15sec. |
Door Sensor Output | NO/COM(0.1A@30VDC) |
Lock Sensor Output | NC/NO/COM(0.1A@30VDC) |
Shear Holding Force | 1200kg |
Door Gap | 2.5mm |
Weight | 1.782kg |
